Air Conditioner Wall Mounting Brackets 140Kg – Part # HA550

Description Large Split System Airconditioner Outdoor Wall Mounting Brackets.Part No. HA550.Wall mounting bracket kit suitable for large split system airconditioners up to 140Kg.Arm lengths 50cm & 56cm. The longer arm is the horizontal arm that supports the air conditioner.Crossbar length 100cm.Mounting slots for airconditioner allow for a minimum depth between holes of 23.5cm and a maximum of 47.5cm. The end of the slot nearest the upright arm is 2cm from the front of the upright arm.The width is fully adjustable up to 94cm.Complete with rubbers to minimise noise & vibration.Painted steel construction.Includes screws to attach the air conditioner unit. Wall mounting hardware such as dynabolts, loxins, coach screws, etc not included.Full instruction sheet can be downloaded by clicking on the picture below.
