Bottom Bracket Adapter – 41mm Press-Fit Cup

Bafang BBS01 BBS02 and BBSHD and Tong Sheng motors are designed to fit conventional threaded bottom Brackets. To fit it onto something else you will need a bottom bracket adapter. If your frame has a 41mm press fit bottom bracket (BB86/92 and some others), the best solution is to use a 68/73mm Bafang motor and the Lekkie Bottom Bracket adapter for 41mm Press Fit (BB86/92) frames (found here). However Tong Sheng motors and some frames aren’t compatible and need a bit more work to get running. A press fit cup has a 41mm outer diameter, which adapts a (41mm) Press fit frame down to 33.5mm allowing fitment of a standard Bafang and Tong Sheng motors. Install 2x Lekkie 41mm Press-Fit Cups where the Lekkie BB86/92 Adapter can’t be fitted. This will allow you to fit a motor of the correct length to a 41mm press-fit BB fat bike or wide BB. You will still need to work out how to lock your motor in place. Note: Discuss your build with us before purchasing. These are mainly used in fat bikes or unique builds. Includes 1x Drive Cup. You will need to purchase 2x cups, one for each side of the BB. Compatibility Bafang BBS01/BBS02/BBSHD, TongSheng Material Forged 6061 T6 Aluminum Finish Anodized Red BB 41mm Inner Diameter BB’s – 86.5mm; 90mm; 91.5mm; 104.5mm; 107mm (DH / Mountain); 121mm (Fat Bike); 132mm (Fat Bike) Weight 10g Version  1 Released 2019.
